LCD screen 4.0-inch IPS color landscape screen 720 * 720 resolution
MIPI interface industrial control screen
Product Overview
1.1 Description
The YT0395B002 is a color active matrix thin film transistor (TFT)
liquid crystal display without polarizer. This model is composed of
amorphous silicon TFT as a switching device. It is a transmissive
type display operating in the normally white mode.
This TFT LCD has a 3.97-inch diagonally measured active display are
a with 720 x 720 dot (720 horizontal by 720 vertical pixel)
resolution. Each pixel is divided into Red, Green, Blue dots which
arearranged in vertical stripe and this module can display 16.7M
colors. The TFT-LCD panel used for this module is adapted for a low
reflection and higher color type.
1.2 Feature
-0.4T Glass(Single)
-Module Design
-RoHS Compliant
1.3 Application
-Smart Watch applications
General specifications
| No. | Item | Specification | Unit |
| 1 | LCD Size | 3.95 | inch |
| 2 | Panel Type | IPS-TFT | - |
| 3 | Resolution | 720 x (RGB) x 720 | pixel |
| 4 | Display Mode | Normally black,Transmissive | - |
| 5 | Display Number of Colors | 16.7M | - |
| 6 | Viewing Direction | ALL | - |
| 7 | Contrast Ratio | 1000 | - |
| 8 | Luminance | 350 | cd/m2 |
| 9 | Module Size | 74.83(W) x 78.98(L) x2.1(D) | mm |
| 10 | Active Area | 71.928(W) x 71.928(L) | mm |
| 11 | Pixel Pitch | 0.0999(W ) x 0.0999(L) | mm |
| 12 | Weight | 33 | g |
| 13 | Driver IC | ST7703 | - |
| 14 | Driver IC RAM Size | 720x24x720 | bit |
| 15 | Light Source | 10 LEDs White | - |
| 16 | Interface | MIPI | - |
| 17 | Operating Temperature | -20~70 | ℃ |
| 18 | Storage Temperature | -30~80 | ℃ |
Product Details
Our factory
Precautions
1. HANDLING
1.1. Polarizer Cleaning, Petroleum N-hexane is recommended for
cleaning the front/rear polarizers and reflectors, toluene and
ethanol are not allowed to avoid damaging the surface.
1.2. Body grounding, must wear Anti-ESD wrist strap while pick up
LCDs.
1.3. FPC Soldering, less than 300℃/3S, solder must be grounding on
grounding bench.
1.4. If use electric Screwdriver to do assembly, screwdriver must
be grounding.
2. STORAGE
2.1. Keep in a sealed polyethylene bag.
2.2. Keep in a dark place.
2.3. Keep in temperature between 0°C and 35°C.
NOT allowed at 70°C for more than 160 Hours, or at -20°C for more than 48 Hrs.
3. SAFETY
If liquid crystal leak out of a damaged glass cell, DO NOT put it
in your mouth or touch eyes, if the liquid crystal touch your skin
or clothes, please wash it off immediately using soap and water.
Limited Warranty
Unless otherwise agreed between ADIA and customer, ADIA will
replace or repair any of its LCD modules which are found to be
functionally defective when inspected in accordance with ADIA LCD
acceptance standards (copies available upon request) for a period
of one year from date of shipments. Cosmetic/visual defects over
specs must be returned to ADIA within 30 days of shipment.
Confirmation of such date shall be based on freight documents. The
warranty liability of ADIA limited to repair and/or replacement on
the terms set forth above. ADIA shall not be responsible for any subsequent or
consequential events.
RETURNING LCM UNDER WARRANTY – TERMS AND CONDITIONS
No warranty can be granted if the precautions stated above have
been disregarded. The typical examples of violations are :
- Broken LCD glass.
- Circuit modified in any way, including addition of components.
Module repairs will be invoiced to the customer upon mutual
agreement. Modules must be returned with sufficient description of
the failures or defects. Any connectors or cable installed by the
customer must be removed completely without damaging the PCB’s eyelet, conductors and terminals.
