7.8 inch long horizontal screen industrial control LCD screen
display screen 800 * 300 LVDS interface 500 brightness
Product Overview
1.1 Description
The AA078AA01 is 7.8" color TFT-LCD (Thin Film Transistor Liquid
Crystal Display) module composed of LCD panel,driver ICs,control
circuit,LED driver and backlight unit.
General specifications
| No. | Item | Specification | Unit |
| 1 | LCD Size | 7.8 | inch |
| 2 | Panel Type | IPS | - |
| 3 | Resolution | 800x3 (RGB) x 300 | pixel |
| 4 | Display Mode | Normally black | - |
| 5 | Display Number of Colors | 262K(6bit/color),16.7M(8bit/color) | - |
| 6 | Viewing Direction | -88~88º(H),-88~88º(V) | - |
| 7 | Contrast Ratio | 1000:1 | - |
| 8 | Luminance | 500 | cd/m2 |
| 9 | Module Size | 207(H ) x 86(V) x10(D) | mm |
| 10 | Active Area | 184.8(H) x 69.3(V) | mm |
| 11 | Pixel Pitch | 0.231(H ) x 0.231(V) | mm |
| 12 | Surface Treatment | Anti-glare and hard-coating 3H | - |
| 13 | Module Mass | 200 | g |
| 14 | Driver IC RAM Size | 240x24x320 | bit |
| 15 | Backlight Unit | LED,edge-light | - |
| 16 | Interface | LVDS(6 bit/8bit) | - |
| 17 | Operating Temperature | -30~80 | ℃ |
| 18 | Storage Temperature | -30~80 | ℃ |
Product Details
Our strengths
Our factory
FAQ
Q1.What is your product range?
A1: We are 12 years of experience manufacturing TFT LCD and touch
screen.
>0.96" to 32" TFT LCD Module;
>Bar type LCD screen up to 48 inch;
>High brightness LCD panel custom;
>Capacitive touch screen up to 55"
>4 wire 5 wire resistive touch screen;
>One-step solution TFT LCD assemble with touch screen.
Q2.Can you custom the LCD or touch screen for me?
A2: Yes we can provide the custom services.
>For the LCD display,backlight brightness and FPC cable can be
customized;
>For the touch screen,we can custom the whole touch panel like
the color,shape,cover thickness and so on according to the
customer's requirement.
>NRE cost will be refunded after the total quantity reaches 1K
pcs.
Q3.Which applications your products are mainly used for?
A3: Embedded system, Intercom system,Biometric,HMI,Smart home
,Robot,Hand-held PDA, after market automotive and etc.
Q4.What's the delivery time?
A4: >For samples order, 1-2weeks;
>For mass ordres,4-6weeks.
Q5.Do you provide free samples?
A5: For first time cooperation,samples will be charged,the amount will
be returned at the mass order stage. In regular cooperation,
samples are free. Sellers keep the right for any change.
