1.77inch 128 * 160 ST7735S driver IC 20PIN MCU interface visible doorbell TFT LCD display screen

Product Overview

1.1 Introduction

The CM-177B64-16-06 is a Color Active Matrix Liquid Crystal Display with a back light system. The matrix employs a-Si Thin Film Transistor as a switching device. This TFT LCD has a 1.77 inch diagonally measured active display area with resolution (128 horizontal by 160 vertical pixels array).

Product Size

General specifications

No.	Items	Speciflcations	Unit
1	Screen Diagonal	1.77	inch
2	Active Area (H x V)	28.03(H)*35.04(V)	mm
3	Number of Pixels (H x V)	128*RGB*160	-
4	Pixel Pitch (H x V)	0.051(H)*0.0153(V)	mm
5	Outline Dimension (H x V x D)	34.70(L)*46.70(H)*2.5(D)	mm
6	Support Color	262K	-
7	Viewing Direction	6 O’clock	-
8	Interface	MCU	-
9	Backlight	2 white LEDs	-
10	Drive IC	ST7735S	-
11	Operating temperature range	-20~70	℃
12	Storage temperature range	-30~80	℃

Product Details

        Founded in 2011, Shenzhen Adia Technology Co., Ltd. is a high-tech private enterprise specializing in R & D, production and sales of liquid crystal display (LCD), liquid crystal display module (LCM), TFT color LCD, touch screen and industrial intelligent serial port screen. And can provide a complete set of display screen and display scheme (PCBA).

        With a variety of standard and differential LCD module (LCM), LCD and TFT color display products. Make LCD and LCM of different specifications and technical requirements according to customers' requirements. The products are widely used in the fields of instruments, smart phones, tablets, POS machines, medical devices, car machines, intelligent robots, smart home, intelligent wearable products, UAVs, VR / AR eyes and military products. The products strive to achieve high quality, micro power consumption, fast delivery, reasonable price and timely technical support. With a wide range of well-known enterprises at home and abroad, the products have been widely used and recognized in the market.

        The company attaches great importance to product quality and strictly implements IOS9001 and RoHS management. Stable quality, professional technical support and timely service are the commitment of Adia to customers. Today, the TFT market is more and more widely used, Adia strives to create a professional and well-known manufacturer of TFT display screen industry with consistent adherence, together with customers and suppliers.
